| Dimensions, Weight & Mount | ||
| External Dimensions (Height x Width x Depth} | mm | 1100x430x195 |
| External Dimensions (Height x Width x Depth} with Flange | mm | 1141x471x195 |
| Weight | Kg | 43 |
| Mounting Method | Door Mounted | |
| Application | Outdoor | |
| Environmental Protection & Performance | ||
| Working Τ emperature Range | ˚C | -40 to +55 |
| Noise Level | dB(A) | 65 |
| Protection from Dust, Water and Wind Driven Rain | IP64 | |
| Refrigerant | R134a | |
| RoHS Compliant | Yes | |
| Cooling/Heating Capacity | ||
| Cooling Capacity@L25/L35 | W | \ |
| Cooling Capacity@L35/L35 | W | 1500 |
| Heating Capacity (Optional) | W | 1000 |
| Power Consumtion | ||
| Power Consumption@L25/L35 | W | \ |
| Power Consumption@L35/L35 | W | 630 |
| Current@L25/L35 | A | \ |
| Current@L35/L35 | A | 3.00 |
| Airflow | ||
| Internal Airflow | M3/h | 350 |
| Power Supply | ||
| Power Supply Range | VDC | -40 to +55, 50/60 |
| Rated operating voltage – Controller | VDC | 48 |
| Rated operating voltage – Cooling/Heating System | VDC | 48 |
| Max. Current | A | 4.0 |
| Key Components | ||
| Controller | Envicool | |
| Fans | Telecom Level | |
| Compressor | Telecom Level | |
| Heater | Telecom Level | |
| External Materials | ||
| Sheet Metal Parts | SECC + Powder Painting | |
| Colour (Optional) | RAL7035 | |
IP Rating Available
0 Minutes Assembly
Available Ready Build
2 Person Assembly
