Features & Benefits
- HQ Polypropylene
- Up to 48F
- Adjustable Cassettes
- Sturdy IP 68 & IK 10
- No Special Tools Required
- Protects Fibres in Field
Applications
- Aerial
- Direct- Burial
- Wall & Terrace Mounting
| SPECIFICATIONS | |
| Purpose | Aerial, Direct-Burial, Wall & Pipeline Mounting |
| Capacity | 48 |
| Cable Entries | 4 |
| Dimensions (mm) | 300×188 |
| Weight (kg) | 1.8-2.2 |
| Sealing | Mechanical |
| Material | Polypropylene |
| Splicing Per Cassette | 12,24 |
| Cable Diameter (mm) | Φ16~22.0 |
| ENVIRONMENTAL SPECIFICATIONS | |
| Operation (°C) | -40~+65 |
| Installation (°C) | -40~+65 |
| ORDERING INFORMATION | |||
| Model | Seal | Cable Entries | Core Size/Capacity |
| DER011 | Mechanical | 4 | 12,24,36,48 |
Up to 72 Fibres
IP 68 Rated
Pole Mountable
Wall Mountable
Direct Buriable
