Features & Benefits
- HQ Polypropylene
- Up to 60F
- Adjustable Cassettes
- Sturdy IP 68 & IK 10
- No Special Tools Required
- Protects Fibres in Field
Applications
- Aerial
- Direct- Burial
- Wall & Terrace Mounting
| SPECIFICATIONS | |
| Purpose | Aerial, Direct-Burial, Wall & Pipeline Mounting |
| Capacity | 60 |
| Cable Entries | 5 |
| Dimensions (mm) | 300 x 220 x 100 |
| Weight (kg) | 2.4-2.7 |
| Sealing | Mechanical |
| Material | Polypropylene |
| Splicing Per Cassette | 15 |
| Cable Diameter (mm) | Φ08~15 |
| ENVIRONMENTAL SPECIFICATIONS | |
| Operation (°C) | -40~+65 |
| Installation (°C) | -40~+65 |
| ORDERING INFORMATION | |||
| Model | Seal | Cable Entries | Core Size/Capacity |
| DER04 | Mechanical | 5 |
12,24,36,48,60,72,84,96,108,120,132,144
|
Up to 144 Fibres
IP 68 Rated
Pole Mountable
Wall Mountable
Direct Buriable
